HI 770 XHD Indirect Air Heater, Diesel, 1x16

HI770XHD Wire assembly Diagram

Exploded parts diagram of the Wire assembly of a Wacker Neuson HI770XHD, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 3135000168316Not stocked
    Clamp×2
  • 5125000167848Not stocked
    Screw×16
  • 5155000167883Not stocked
    Screw×16
  • 5175000167793Not stocked
    Screw×2
  • 6095000181653Not stocked
    Terminal-heat shrink×1
  • 6105000181652Not stocked
    Terminal-heat shrink×1
  • 6125000181651Not stocked
    Terminal-heat shrink×1
  • 6155000181650Not stocked
    Terminal-heat shrink×3
  • 6355000166724Not stocked
    Switch×1
  • 6545000166765Not stocked
    Wire×1
  • 6555000166763Not stocked
    Wire×1
  • 6575000166683Not stocked
    Junction box×1
  • 6665000166610Not stocked
    Light×4
  • 6675200005411Not stocked
    Light bulb×4
  • 6695100034437Not stocked
    Breakaway Kit×1
