RD28e-120c

RD28-120CE compactometer Diagram

Exploded parts diagram of the compactometer of a Wacker Neuson RD28-120CE, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 35100073090Not stocked
    holder system×1
  • 45100012718
    $1.66
    Cheese-head screw - 5100012718×2
  • 55100012936
    $2.27
    Washer - 5100012936×2
  • 65100033252Not stocked
    bushing×2
  • 105100033253Not stocked
    calculator×1
  • 115100033254
    $1.49
    cheese-head screw - 5100033254×2
  • 125100013453
    $1.49
    Washer - 5100013453×2
  • 135100012936
    $2.27
    Washer - 5100012936×2
  • 145100012898
    $3.15
    Hexagon nut - 5100012898×2
  • 205100033258Not stocked
    acceleration sensor×1
  • 215100033260Not stocked
    cheese-head screw×2
  • 255100073101Not stocked
    holder×1
  • 265100013510
    $1.57
    Hexagon screw - 5100013510×2
  • 275100012966
    $1.57
    Locking washer - 5100012966×2
  • 305100077713Not stocked
    cable harness×1
