WL52

WL52 screw joint valve Diagram

Exploded parts diagram of the screw joint valve of a Wacker Neuson WL52, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000360278Not stocked
    bracket valve×1
  • 21000085353
    $1.03
    hex screw M8x120-8.8 A2C - 1000085353×2
  • 31000085390
    $0.83
    6-Point screw M8x30-8.8 A2C-DIN933 - 1000085390×2
  • 41000015431Not stocked
    washer×8
  • 51000226476
    $54.45
    LOCK SCREW CONNECTION - 1000226476×1
  • 61000013022Not stocked
    hexagon nut×4
  • 71000085096
    $9.05
    GE22LREDOMDA3C - 1000085096×2
  • 81000085074
    $9.23
    GE15LR3/4EDOMDA3C - 1000085074×1
  • 91000085124
    $24.29
    ET22LOMDA3C - 1000085124×1
  • 101000015513Not stocked
    screw joint×1
  • 111000015512Not stocked
    screw joint×1
  • 121000030655Not stocked
    lock screw×1
  • 131000327291Not stocked
    screw connection×1
  • 141000020261
    $17.85
    EW22LOMD - 1000020261×1
