WL52

WL52 quickhitch plate Diagram

Exploded parts diagram of the quickhitch plate of a Wacker Neuson WL52, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000402739Not stocked
    adapter frame×1
  • 21000354340
    $600.80
    Cylinder - 1000354340×1
  • 31000406860
    $237.33
    Bolt - 1000406860×2
  • 41000560564Not stocked
    pin×2
  • 51000224688
    $151.67
    Pin 1000224688×2
  • 61000047409Not stocked
    hex screw×2
  • 71000196350
    $36.42
    Sleeve - 1000196350×2
  • 81000049060Not stocked
    hexagon nut×2
  • 91000348218Not stocked
    Hose×2
  • 101000418875Not stocked
    Hose×1
  • 111000346390
    $64.57
    Solenoid - 1000346390×1
  • 121000015491Not stocked
    screw joint×1
  • 131000367370Not stocked
    seal kit valve cartridge×1
  • 141000264768
    $54.49
    EWE10LR 3/8" - 1000264768×3
  • 151000013009Not stocked
    hex screw×4
  • 161000222577
    $1.45
    Washer - 1000222577×4
  • 171000406859Not stocked
    shim×2
  • 181000222854
    $1.27
    SCREW-HEX - 1000222854×2
  • 191000015405Not stocked
    hexagon nut×2
  • 201000222875
    $5.40
    Washer - 1000222875×4
  • 211000222726
    $1.34
    NIPPLE-GREASE - 1000222726×2
  • 221000468985Not stocked
    cylinder seal kit×1
  • 231000335644
    $216.58
    Valve - 1000335644×1
  • 241000265570
    $198.75
    drive valve - 1000265570×1
