WL60

WL60T4F compressor aircondition Diagram

Exploded parts diagram of the compressor aircondition of a Wacker Neuson WL60T4F, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000085322
    $1.31
    hex screw - 1000085322×4
  • 21000298037
    $769.05
    Bracketcompressor 1000298037×1
  • 31000308560Not stocked
    flat belt×1
  • 41000330826
    $64.09
    Adapter - 1000330826×1
  • 51000379801Not stocked
    refrigerant sticker×1
  • 61000022386Not stocked
    cheese head screw×2
  • 71000015431Not stocked
    washer×9
  • 81000030951Not stocked
    spring washer×4
  • 91000048176Not stocked
    cheese head screw×3
