G130 Generator,T4F, URI HVAC

Despiece de Option-Fuel Quick Disconnect · G130

Despiece del Option-Fuel Quick Disconnect de una máquina Wacker Neuson G130, con globos numerados
Pasa por encima de un recuadro para ver la pieza, su precio y su fila. Pincha para marcarla.
  • 2805200024166No la vendemos
    Fuel fill port×1
  • 8335000028949
    $0.29
    SCREW M6 X 16,HX.HD,SER.FLG - 5000028949×4
  • 8385000028404
    $0.26
    SCREW M8 X 20,HX.HD,SER.FLG - 5000028404×2
  • 9135000010368
    $0.10
    NUT-LOCK M6 HEX. - 5000010368×4
  • 9205000115570
    $0.12
    Nut M8 Flange, Non serrated - 5000115570×2
  • 9525000010628
    $0.02
    WASHER A4.3 FLAT - 5000010628×2
  • 9545000010624
    $0.03
    WASHER B6.4 FLAT - 5000010624×4
  • 12005200025293No la vendemos
    Bracket×1
  • 12015200025294No la vendemos
    Handle×1
  • 12105200025295No la vendemos
    Fuel valve×2
  • 12135200022715No la vendemos
    Fitting×5
  • 12145200025557No la vendemos
    Fitting×1
  • 12155200005250
    $10.48
    FITTING-REDUCER 1/2NPTF TO 3/8NPTM - 5200005250×1
  • 12175000180571
    $8.60
    FITTING-ELBOW,3/8 NPTFX3/8 NPT - 5000180571×2
  • 12185200001623
    $31.87
    COUPLER-ISO 7241-1B 3/8 MALE - 5200001623×1
  • 12195200024167No la vendemos
    Coupling×1
  • 12205000181823
    $8.58
    FITTING-3/8 BARB X 3/8 F.NPT - 5000181823×2
  • 12335200015822No la vendemos
    Fuel hose×2
  • 12355200007891
    $8.02
    HOSE-FUEL 3/8 x 800MM - 5200007891×1
  • 12415000181825
    $7.96
    HOSE-FUEL 3/8 X 500MM - 5000181825×2
  • 12455100028097
    $15.57
    HOSE-FUEL 3/8 x 970MM - 5100028097×1
  • 12605000028329
    $0.25
    SCREW #8-32 X 1/4,HX.HD.MACH. - 5000028329×2
