SPARE PARTS LIST 1200/2002 SP

1200/2002 engine hood Diagram

Exploded parts diagram of the engine hood of a Wacker Neuson 1200/2002, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000017833Not stocked
    rubber profile×1
  • 21000064940Not stocked
    engine hood×1
  • 31000064943Not stocked
    piece hinge×1
  • 41000064986Not stocked
    drivers seat×1
  • 51000065132Not stocked
    hinge pin×2
  • 61000001779Not stocked
    gas strut×1
  • 71000003253Not stocked
    bonnet buckle×1
  • 81000065204
    $15.21
    HANDLE - 1000065204×2
  • 91000085390
    $0.83
    6-Point screw M8x30-8.8 A2C-DIN933 - 1000085390×14
  • 101000085379
    $1.08
    hex screw - 1000085379×4
  • 111000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×2
  • 121000085587
    $0.03
    HEXAGON NUT - 1000085587×1
  • 131000015431Not stocked
    washer×3
  • 141000064987Not stocked
    seat upholstery×1
  • 151000064988Not stocked
    back cushion×1
