SPARE PARTS LIST 1200/2002 SP

1200/2002 cooler Diagram

Exploded parts diagram of the cooler of a Wacker Neuson 1200/2002, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000065006Not stocked
    bracket cooler×1
  • 21000065014Not stocked
    combicooler×1
  • 31000065166Not stocked
    buffer×2
  • 41000101601Not stocked
    buffer×2
  • 51000015343Not stocked
    hex screw×1
  • 61000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×2
  • 71000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×1
  • 81000015431Not stocked
    washer×2
  • 91000092303
    $0.86
    Washer 10,5 St A2C - 1000092303×2
  • 101000001930Not stocked
    cooler cap×1
  • 111000083292Not stocked
    hose clamp×3
  • 121000147636
    $4.88
    SCDIES 8,0 - 1000147636×0.5
  • 131000147636
    $4.88
    SCDIES 8,0 - 1000147636×1
  • 141000067377Not stocked
    hose clamp×4
  • 151000077592Not stocked
    hose×0.3
  • 161000077592Not stocked
    hose×0.85
