5001 control valve Diagram

Exploded parts diagram of the control valve of a Wacker Neuson 5001, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

11000272063
$761.04
Controlvalve 1000272063×1
21000166700
$18.12
Lever Adapter - 1000166700×1
31000082587
$0.70
HEXAGON NUT - 1000082587×1
41000068345
$11.42
GN539-23-M10 - 1000068345×1
51000125340
$24.08
COVER - 1000125340×1
61000022334Not stocked
hex screw×3
71000015448Not stocked
washer×6
81000015416
$0.71
DIN985-M8-8-A2C - 1000015416×3
91000015494Not stocked
screw joint×1
101000015506Not stocked
screw joint×2
111000015490Not stocked
screw joint×2
121000015491Not stocked
screw joint×2
131000015533Not stocked
screw joint×1
141000015512Not stocked
screw joint×1
151000020801
$12.87
GZ15LA3C - 1000020801×1
161000028582Not stocked
minimess point×1
171000085128
$3.13
GE12LR1/4EDOMDA3C - 1000085128×1
181000173372
$239.78
lever fastening set - 1000173372×1
191000095097
$1.38
O-RING - 1000095097×2
201000095091
$0.38
O-RING - 1000095091×4
211000173346
$33.23
back adjust stick set - 1000173346×2
221000152286
$84.01
pressure limit reliefvalve - 1000152286×1
231000228724
$26.44
BELLOW - 1000228724×1
