5001 skip Diagram

Exploded parts diagram of the skip of a Wacker Neuson 5001, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

11000319852
$18,542.15
powerswivel - 1000319852×1
21000319853Not stocked
powerswivel×1
31000104147
$63.58
bucket tilt pin - 1000104147×2
41000104045
$63.38
Pintiltram 1000104045×1
51000015364Not stocked
hex screw×5
61000015438Not stocked
lock washer×3
71000094974
$0.70
washer M10-DIN134 - 1000094974×3
81000353884Not stocked
maintenance support×1
91000015457Not stocked
cotter pin×1
101000015407Not stocked
hexagon nut×2
111000085339
$2.84
hex screw - 1000085339×1
121000020788Not stocked
hexagon nut×1
131000166691
$131.80
Swivellock 1000166691×1
141000163520
$9.16
hex screw - 1000163520×1
151000049089Not stocked
hexagon nut×1
