DW90 Dumper

DW90 battery Diagram

Exploded parts diagram of the battery of a Wacker Neuson DW90, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000081788Not stocked
    battery×1
  • 21000254627
    $36.00
    BATTERY DISCONNECT SWITCH COMPLETE - 1000254627×1
  • 31000252807
    $9.96
    bracket battery - 1000252807×2
  • 41000280523
    $15.29
    clamp - 1000280523×1
  • 51000015436Not stocked
    lock washer×4
  • 61000015430Not stocked
    u-washer×8
  • 71000085457
    $0.13
    allen screw M6x25-8.8 A2C DIN912 - 1000085457×2
  • 81000332032Not stocked
    plus cable×1
  • 91000018400Not stocked
    hex screw×8
  • 101000085588
    $0.32
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×4
  • 111000300771
    $242.28
    plus cable - 1000300771×1
  • 121000300750
    $148.25
    plus cable - 1000300750×1
  • 131000332559Not stocked
    minus cable×1
  • 141000069051Not stocked
    battery cable×1
  • 151000239194
    $11.20
    terminal cap - 1000239194×1
  • 161000084909
    $8.47
    cutoff switch key - 1000084909×1
  • 171000097928
    $4.57
    edge protection - 1000097928×12
  • 181000097928
    $4.57
    edge protection - 1000097928×12
  • 191000273710
    $13.79
    cutoff switch key - 1000273710×1
  • 201000273724
    $4.94
    Dustcap 1000273724×1
