G25-GENERATOR COLD WEATHER

G25 Option-Radiator Shutter Diagram

Exploded parts diagram of the Option-Radiator Shutter of a Wacker Neuson G25, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000180310
    $1,725.42
    SHUTTER FRAME, for 5000161051 - 5000180310×1
  • 25000180311Not stocked
    Actuator×1
  • 35000171921
    $38.14
    ROD-CONTROLLER - 5000171921×1
  • 35000171922
    $55.55
    FITTING-END - 5000171922×1
  • 35000171923
    $0.52
    NUT-HEX - 5000171923×2
  • 35000171924
    $0.81
    NUT-LOCK - 5000171924×1
  • 45200014743Not stocked
    Hose×1
  • 55200014742Not stocked
    Hose×1
  • 65000171926
    $6.95
    FITTING-90 DEG. ELBOW - 5000171926×1
  • 75000171927
    $12.57
    Fitting - 5000171927×2
  • 85000171928
    $5.35
    CLAMP-THREADED HOSE - 5000171928×4
  • 125000171932
    $43.96
    PIN-THREADED PIVOT - 5000171932×1
  • 125000171933
    $0.84
    C-CLIP - 5000171933×1
  • 155000171936
    $18.98
    SPRING-EXTENSION - 5000171936×1
  • 1015000157244
    $29.81
    Panel-Rad Cover,Wht AL,P-5000177670 - 5000157244×1
  • 2255000161051
    $2,688.36
    Radiator Shutter Cpl., SMALL - 5000161051×1
  • 6125000158849
    $1.89
    GASKET-RADIATOR COVER - 5000158849×1
  • 6145000161461
    $9.12
    GASKET-RUBBER 1/8 TX3/4 WX6'L - 5000161461×1
  • 8695000158897
    $0.25
    SCREW M8X20 HX.HD.,SST - 5000158897×9
  • 8885000161194
    $0.29
    SCREW M8X25 HX.HD.,A2 304,SST - 5000161194×5
  • 9635000158899
    $0.07
    WASHER M8 FLAT,SST - 5000158899×11
  • 10005200012588Not stocked
    Vane replacement kit×1
