GS12Ai

GS12AI Alternator cpl. Diagram

Exploded parts diagram of the Alternator cpl. of a Wacker Neuson GS12AI, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 4005100001474Not stocked
    Generator cpl.×1
  • 4055000170860Not stocked
    Ring×1
  • 4075000170855Not stocked
    Fan Wheel×1
  • 4085100002457Not stocked
    collector×1
  • 4105000170861Not stocked
    Carbon brush cpl. With Bracket×1
  • 4135000170856Not stocked
    Ball bearing×1
  • 4145000170862Not stocked
    Control panel×1
  • 4155100001475Not stocked
    Transformer×1
  • 4165000157443Not stocked
    Diode×1
  • 4175100002458Not stocked
    Terminal board×1
  • 4185000170857Not stocked
    Terminal board×1
  • 4205000170859Not stocked
    Screen grid×1
  • 4245000170847Not stocked
    Cover×1
