HSH350 DG,HEATER-SURFACE 50Hz
HSH350 Oil Pump/Governor Diagram
- PUMP-OIL - 5000207031×1
- RING-SNAP - 5000207032×1
- STRAP-RETAINING - 5000108778×1
- BALL 3.5MM - 5000108779×1
- SCREW-ALLEN M5X12 - 5000151308×4
- SPRING-FLAT 0.4MM - 5000108777×1
- TUBE-SUCTION,OIL - 5000108775×1
- INSERT-TUBE - 5000108774×1
- INSERT-TUBE - 5000108776×1
- SHAFT - 5000108781×1
- CLIP-CIRCLE - 5000108780×2
- Lever - 5000108785×1
- LEVER-GOVERNOR - 5000151316×1
- SCREW-ALLEN M3X12 - 5000151318×2
- PLATE-INTERMEDIATE - 5000108789×1
- SPRING-GOVERNOR 0.2MM - 5000151320Unknown×1
- 215200007457Not stockedGovernor spring×1
- SPRING-GOVERNOR 0.3MM - 5000151321×1
- SPRING-STOP - 5000151322×1
- NUT M6,HEX - 5000207588×1
- WASHER-FLAT 6.4 - 5000151324×1
- Lever - 5000151325×1
- SCREW M6X32 - 5000107624×1
- CLIP-CIRCLE 7 - 5000151327×2
- Regulator - 5000212093×1
- PLATE - 5000151330×1
- X-5000108801-O-RING 8X2,GRAY - 5000151336×1
- SCREW M5X12 -10.9 ZN - 5000151328×1
- SCREW-ECCENTRIC - 5000129004×2
- WEIGHT-GOVERNOR - 5000207034×4
- SLEEVE-GOVERNOR - 5000108773×1
- NUT M5 5 A3C - 5000151335×1
- CONTROL-STOP - 5000151331×1
- WASHER 5.3, A3C - 5000129517×1
- SCREW M5X25 8.8 - 5000151333×1
- SPRING-TENSION - 5000209739×1
- Spring - 5000207033×1
- CONTROL-STOP - 5000108787×1
- SCREW-ALLEN M3X8 - 5000108788×2
- WEIGHT-CENTRIFUGAL - 5000207035×4
- PLUG 8X3.2X0.5 - 5000151351×1
- SPRING - 5000151352×1
- SCREW-GRUB M10X10 A3C - 5000151353×1
- SHIM 8X14X1 - 5000151354×3
- Spring - 5000209715×1
- BUSHING - 5000209714×1
- SCREW-SET M5X10 TUF360G - 5000151342×1
