HSH350 DG,HEATER-SURFACE 50Hz

HSH350 Pump-Heat Transfer Fluid Diagram

Exploded parts diagram of the Pump-Heat Transfer Fluid of a Wacker Neuson HSH350, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 2005000168110Not stocked
    Adapter×1
  • 2325000168277Not stocked
    Pump×1
  • 3015000168284Not stocked
    Hose barb×1
  • 3215000168374Not stocked
    Adapter×2
  • 3245000168458Not stocked
    Bushing×1
  • 3335000168111Not stocked
    Coupling×1
  • 3405000168031Not stocked
    Elbow×1
  • 3465000168353Not stocked
    Nipple fitting×2
  • 3555000168479Not stocked
    Tee-fitting×1
  • 3595000168351Not stocked
    Check valve×1
  • 5055000167704Not stocked
    Bolt×3
  • 5075000167705Not stocked
    Bolt×4
  • 5465000167733Not stocked
    Lock washer×3
  • 5475000167735Not stocked
    Lock washer×4
  • 5505000166459Not stocked
    Lock nut×1
  • 6035000166544Not stocked
    Motor×1
  • 6095000166458Not stocked
    Cord grip×1
