RTLx-SC3

RTSC3 Smooth Drum Diagram

Exploded parts diagram of the Smooth Drum of a Wacker Neuson RTSC3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000171665
    $825.58
    DRUM 820MM,SMOOTH - 5000171665×2
  • 25200006892
    $520.77
    SCRAPER-ANGLE,RT P-5000112006 - 5200006892×4
  • 35000013002
    $0.37
    SCREW M12 X 25 HX.HD. - 5000013002×6
  • 45000017087
    $2.33
    SCREW M12 X 30 10.9,SOC - 5000017087×12
  • 55000011524
    $1.56
    SCREW M16 X 25 HX.HD. - 5000011524×12
  • 65000031826
    $3.38
    SCREW M16 X 16 HX.HD. - 5000031826×6
  • 75000011544
    $0.44
    SCREW M8 X 16 SOC.HD. - 5000011544×1
  • 85000180963
    $1.91
    SCREW-SET M12X35 SOC. - 5000180963×6
  • 95000031565
    $0.48
    WASHER-LOCK A12 - 5000031565×18
  • 105200009076
    $0.41
    WASHER-M16, THICK - 5200009076×6
  • 115100055712
    $6.86
    BUMPER, DRUM SUPPORT - 5100055712×1
  • 125002004814
    $74.83
    SHOCKMOUNT 100 X 58-45SH,FRM C - 5002004814×6
