DW50
DW50 front frame Diagram
- Slewingring 1000116919×1
- 21000015423Not stockedhexagon nut×8
- HEX SCREW - 1000085429×8
- spacer - 1000344203×4
- spacer - 1000344204×4
- spacer - 1000344205×4
- 71000015476Not stockedgrease nipple×3
- 81000020553Not stockedhex screw×2
- 91000015437Not stockedlock washer×1
- hex screw M8x40-8.8 A2C DIN933 - 1000085392×1
- 111000022379Not stockedcover plate×1
- clamp - 1000353324×1
- SLEWING RAM PIN - 1000116720×2
- 141000015438Not stockedlock washer×6
- washer 10,5 A2C DIN125 - 1000015432×6
- 161000015364Not stockedhex screw×6
- 171000015480Not stockedcap grease nipple×2
- 181000018400Not stockedhex screw×2
- 191000015436Not stockedlock washer×2
- washer A 6,4 St A2C DIN9021 - 1000095343×3
- CHAIN - 1000097224×0.65
- 221000015457Not stockedcotter pin×1
- hex screw - 1000141354×1
- 241000018412Not stockedhexagon nut×1
- pin - 1000341831×1
- 261000342377Not stockedbuckle support×1
- 271000065198Not stockedfastener rail×2
- 281000065197Not stockeddust catch×2
- Dustcatchbracket 1000116917×1
- washer A 5,3 A2C DIN125 - 1000094962×8
- Dustcatchbracket 1000116918×1
- ovalhead screw - 1000085549×8
- HEXAGON NUT - 1000085581×8
- 341000015451Not stockednorthlock disc×16
