Pureheat Hydronic Heater, Oil Burner

PUREHEAT Fuel System Diagram

Exploded parts diagram of the Fuel System of a Wacker Neuson PUREHEAT, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 155000167758Not stocked
    Bolt×4
  • 445000167202Not stocked
    Adapter plate×1
  • 2135000168078Not stocked
    Filter housing×1
  • 2425200000922Not stocked
    Burner×1
  • 2475000169178Not stocked
    Gasket×1
  • 2485000168038Not stocked
    Hose clamp×4
  • 3135000166030Not stocked
    Hose cpl.×1
  • 3135000168280Not stocked
    Hose barb×2
  • 3345000168012Not stocked
    Quick coupler×2
  • 3365000168010Not stocked
    Quick coupler×2
  • 3505000168073Not stocked
    Nipple fitting×1
  • 3785000168595Not stocked
    Hose barb×2
  • 5005000166031Not stocked
    Hose cpl.×1
  • 5005000167699Not stocked
    Bolt×4
  • 5405000167728Not stocked
    Flat washer×6
  • 5455000167734Not stocked
    Lock washer×4
  • 6555000166068Not stocked
    Cable cpl.×1
  • 10005000168966Not stocked
    Filter Element Set×1
  • 10015100025232
    $131.19
    NOZZLE LINE ASSEMBLY - 5100025232×1
