RD15 ROLLER,DOUBLE DRUM
RD15 Driving/Vibration Drum Diagram
- NLA WASHER 10.5 X 21 X 2 - 5000117928×14
- SCREW M10 X 50 HX.HD. - 5000011320×14
- NLA SPACER - 5000117881×2
- Plate - 5000117882×4
- NLA WASHER 10.5 X 16 X 1 - 5000117927×16
- BOLT - 5000112791×16
- Plug - 5000117883×2
- NLA WASHER-COPPER - 5000113264×2
- NLA HUB - 5000117884×2
- bearing - 5000117885×4
- Shaft - 5000117886×2
- NUT-LOCK - 5000113471×6
- NLA WASHER 10.5 X 21 X 2 - 5000117928×8
- BOLT - 5000112770×8
- WASHER 17 X 30 X 4 - 5000117929×12
- SCREW M16 X 30 HX.HD. - 5000011523×12
- NLA WASHER 8.4 X 13 X 1.4 - 5000117930×8
- BOLT - 5000113242×8
- Ring - 5000112852×2
- Cover - 5000113639×2
- COUPLING - 5000112491×2
- Gear - 5000112609×2
- Ring - 5000112854×2
- NLA HUB - 5000117887×2
- INDICATOR-LEVEL - 5000117888×2
- NLA WASHER-COPPER - 5000117931×2
- SCREW M6 X 25 SOC.HD. - 5000011550×10
- NLA WASHER 6.4 X 10 X 1.2 - 5000117932×10
- NLA HUB-SUPPORT - 5000117889×2
- NLA BEARING - 5000112458×4
- BOLT - 5000112770×24
- NLA WASHER 10.5 X 21 X 2 - 5000117928×24
- SEAL-OIL - 5000117891×2
- Shockmount - 5000117892×12
- Drum - 5000117893×2
