RD15 ROLLER,DOUBLE DRUM
RD15 Steering System Central Articulation Diagram
- Hub - 5000112640×1
- BOLT - 5000113454×4
- PendX-5000162023 Washer - 5000112830×4
- NLA NUT-LOCK - 5000112807×4
- HUB - 5000112642×1
- BEARING-BALL - 5000113431×2
- Washer - 5000113473×2
- Nut - 5000113472×2
- PIN - 5000113625×1
- CLAMP - 5000113674×1
- BOLT - 5000113464×1
- Washer - 5000112818×2
- BEARING - 5000112469×2
- Ring - 5000112464×1
- PIN - 5000113630×1
- NLA WASHER - 5000113480×2
- PIN-SPLIT - 5000113497×2
- CONNECTING ROD - 5000113637×1
- NLA PIN - 5000113631×1
- NLA PIN - 5000112729×1
- SHIM - 5000113647×1
- FITTING-GREASE - 5000112724×2
- FITTING-GREASE - 5000113438×2
- RETAINING RING-EXT. - 5000113492×4
- Washer - 5000113481×4
- NLA SPACER - 5000113642×4
- PIN - 5000113624×2
