RD28-120c CN

RD28-120CCN sprinkling Diagram

Exploded parts diagram of the sprinkling of a Wacker Neuson RD28-120CCN, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 855100070419Not stocked
    water pump×1
  • 865100012919
    $18.55
    Silentbloc - 5100012919×4
  • 875100013523
    $1.57
    Washer - 5100013523×4
  • 885100012545
    $1.57
    Hexagon nut - 5100012545×8
  • 925100011527
    $8.02
    Angle screwed socket - 5100011527×1
  • 935100013646
    $44.44
    Flexible tubing - 5100013646×0.5
  • 945100011666
    $7.38
    Angle screwed socket - 5100011666×1
  • 955100011670
    $24.55
    Flexible tubing - 5100011670×0.8
  • 965100070421Not stocked
    holder×1
  • 975100013531
    $1.79
    Filler cap - 5100013531×1
  • 1205100013573
    $1.49
    Wire fastener - 5100013573×6
