RTD-SC4 TRENCH ROLLER
RT-SC4 Flywheel Complete Diagram
- FLYWHEEL ASSEMBLY - 5000159485×1
- GEAR-CROWN - 5000155693×1
- BOLT M10 X 35 - 5000160188×5
- ALTERNATOR ROTOR - 5000159258×1
- FLANGE-CRANKSHAFT - 5000159281×1
- GASKET-FLANGE - 5000159296×1
- SEAL-RING - 5000103314×1
- 85200023965Not stockedScrew×6
- COUPLING COMPLETE,HYDRAULIC - 5000161077×1
- SCREW M10 X 30 - 5000084164×3
- HOUSING-BELL - 5000161076×1
- SPACER - 5000161078×1
- PIN-DOWEL - 5000161080×1
- NUT M8 - 5000082140×5
- SCREW M8 X 25 - 5000084123×7
- PLATE-FLANGE - 5000159326×1
- BOLT M8 X 14 - 5000159254×7
