RT560 CC-CE TRENCH ROLLER

RT560 Oil Cooler Diagram

Exploded parts diagram of the Oil Cooler of a Wacker Neuson RT560, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000086397
    $23.23
    SEAL-TRIM,RADIATR,FRONT,34.75 - 5000086397×1
  • 25000079363
    $0.36
    SCREW M8 X 16,HX.HD,SER.FLG - 5000079363×8
  • 35000086378
    $107.83
    COVER-RADIATOR P-5000112006 - 5000086378×1
  • 45000155405
    $1,103.44
    RADIATOR-HEAT EXCHANGER - 5000155405×1
  • 55000010367
    $0.10
    NUT-LOCK M8 HEX - 5000010367×3
  • 65000011449
    $0.35
    SCREW M8 X 65,HX.HD. - 5000011449×1
  • 75000010622
    $0.10
    WASHER-FLAT,M8,ZINC - 5000010622×2
  • 85000155404
    $3.97
    WASHER 1.25X1.0X.34 DIA,SQ - 5000155404×5
  • 95000011448
    $0.43
    SCREW M8 X 70,HX.HD. - 5000011448×2
  • 105000086383
    $454.99
    BASEPLATE-RADIATOR ASSY P-5000112006 - 5000086383×1
  • 115000086398
    $12.09
    SEAL-TRIM,RADIATOR,REAR,28.50 - 5000086398×1
  • 125000086581
    $15.41
    FITTING-SDE45,08X08ST - 5000086581×2
  • 135000080732
    $0.32
    O-RING .644 X.087 DURO90 3-908 - 5000080732×2
  • 145000080737
    $0.15
    O-RING .49 X .07 #8 ORFS 2-014 - 5000080737×2
  • 155000086394
    $90.74
    HOSE-HYD ASSY.08ID X 67 LG - 5000086394×2
  • 165000086393
    $276.75
    VALVE-BYPASS,CHECK - 5000086393×1
  • 175000078871
    $13.89
    FITTING-HYD,BEADED - 5000078871×1
  • 185000080734
    $0.56
    O-RING .924 X.116 DURO90 3-912 - 5000080734×1
  • 195000086399
    $242.35
    BRACKET-VALVE,CHECK P-5000112006 - 5000086399×1
  • 205000028949
    $0.29
    SCREW M6 X 16,HX.HD,SER.FLG - 5000028949×2
  • 215000028314
    $0.78
    CLAMP-THREADED,.81-1.5 - 5000028314×2
  • 225000086391Not stocked
    Hose×1
  • 235000012361
    $0.23
    SCREW M8 X 16 HX.HD. - 5000012361×2
  • 245000155406
    $28.17
    MOUNT-RUBBER BLOCK - 5000155406×3
  • 255000088412
    $710.49
    KIT-RADIATOR,COMPLETE - 5000088412×1
