RTLx-SC3 - Smooth Drum

RTLX-SC3 Exciter Shaft Diagram

Exploded parts diagram of the Exciter Shaft of a Wacker Neuson RTLX-SC3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100054549
    $3,475.95
    Drum Support, Rt 5100054549×1
  • 25100055690
    $91.94
    COVER-BEARING HOLDER P-5000176420 - 5100055690×1
  • 35100055649
    $141.60
    COVER-EXCITER MOTOR P-5000176420 - 5100055649×1
  • 45100055646
    $46.60
    COVER-MACHINED - 5100055646×2
  • 55000080742
    $43.35
    BEARING-CYLINDER - 5000080742×4
  • 65200001515
    $293.45
    GEAR-EXCITER,COMPOSITE - 5200001515×2
  • 75000171035
    $26.03
    WEIGHT-EXCITER,LH - 5000171035×2
  • 85000171034
    $26.03
    WEIGHT-EXCITER,RH - 5000171034×2
  • 95000171033
    $414.96
    SHAFT-EXCITER W/COUNTERBORE - 5000171033×1
  • 105000171032
    $375.52
    SHAFT-EXCITER W/O COUNTERBORE - 5000171032×1
  • 115000171028
    $0.90
    RET.RING,EXT SPIRAL 45X1.69DIN - 5000171028×4
  • 125000163948
    $0.35
    SCREW M8X16 HX FLG BL ZN 8.8,W/202 - 5000163948×6
  • 135000011457
    $1.49
    SCREW M8 X 25 HX.HD. - 5000011457×12
  • 145000013552
    $0.33
    SCREW M8 X 10 HX.HD. - 5000013552×4
  • 155000115699
    $1.10
    KEY A10 X 8 X 16 - 5000115699×2
  • 165000171446
    $353.01
    KIT-EXCITER SHAFT W/CNTRBORE - 5000171446×1
  • 175000171445
    $513.60
    KIT-EXCITER SHAFT W/O CNTRBORE - 5000171445×1
