ST35 Compact Track Loader

ST35(S04-02) air cleaner Diagram

Exploded parts diagram of the air cleaner of a Wacker Neuson ST35(S04-02), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000032165Not stocked
    Air cleaner×1
  • 21000270266
    $13.72
    dirt indicator - 1000270266×1
  • 31000031896Not stocked
    Clamp×1
  • 41000013014Not stocked
    Cheese head screw×2
  • 51000013027Not stocked
    washer×2
  • 61000083296
    $10.85
    Hose Clamp - 1000083296×1
  • 71000015437Not stocked
    Lock washer×2
  • 81000290640
    $372.10
    Hoseairintake 1000290640×1
  • 91000159596
    $46.15
    pipe clamp - 1000159596×2
  • 101000087796
    $20.81
    airfilter insert - 1000087796×1
  • 111000000365Not stocked
    Filter cartridge×1
  • 121000088788
    $15.77
    Cover - 1000088788×1
  • 131000084971
    $6.25
    dustexhaust valve - 1000084971×1
  • 141000313497Not stocked
    thread rod×1
  • 151000083322
    $4.17
    hose clamp 87-112mm - 1000083322×1
