ST45

ST45 Kit—Bucket Position Diagram

Exploded parts diagram of the Kit—Bucket Position of a Wacker Neuson ST45, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000558151Not stocked
    DIA KIT BUCKET POSITION VERT×1
  • 21000543177Not stocked
    VALVE BUCKET LEVELING VERTICAL 275 BAR×1
  • 31000545748Not stocked
    TUBELINE HYD ASSY×1
  • 41000545749Not stocked
    TUBELINE HYD ASSY×1
  • 51000545746Not stocked
    TUBELINE HYD ASSY×1
  • 61000545747Not stocked
    TUBELINE HYD ASSY×1
  • 71000409240Not stocked
    Tee fitting×2
  • 81000340644Not stocked
    Tee fitting×2
  • 91000343326Not stocked
    Elbow fitting×2
  • 101000388531Not stocked
    Fitting×2
  • 111000343153Not stocked
    Hexagon nut×2
  • 121000446237
    $1.21
    BOLT-CARRIAGE.SHRT.NK-M8x80-8.8-ZNC - 1000446237×2
  • 131000343350
    $0.18
    NUT M8 FLANGED LOCKNUT 8 ZINC - 1000343350×2
  • 141000342317Not stocked
    Rocker switch×1
  • 151000558152Not stocked
    INSTRUCTIONS DIA KIT BUCKET POSITION×1
