Vibroplate xPU KMAT

XPUKMAT Extension plate kitDPU/BPU 52/62 Diagram

Exploded parts diagram of the Extension plate kitDPU/BPU 52/62 of a Wacker Neuson XPUKMAT, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 105100070830Not stocked
    Lock washer×8
  • 205100064495Not stocked
    Hexagonal head cap screw×8
  • 305100064498Not stocked
    Extension plate×2
  • 405100082421Not stocked
    Extension plate XPU 52/62×1
