WN Excavator 6003

6003 joystick Diagram

Exploded parts diagram of the joystick of a Wacker Neuson 6003, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000161732Not stocked
    valve×2
  • 21000064799Not stocked
    cross union×2
  • 31000015488Not stocked
    screw joint×4
  • 41000085456
    $0.05
    allen screw M6x20-8.8 A2C-DIN912 - 1000085456×8
  • 51000015436Not stocked
    lock washer×8
  • 61000015430Not stocked
    u-washer×8
  • 71000021259Not stocked
    PLUNGER KIT×2
  • 81000019515Not stocked
    rubber cap set×2
  • 91000015488Not stocked
    screw joint×4
  • 101000015576Not stocked
    non return valve×3
  • 111000468097Not stocked
    filter×1
  • 121000015488Not stocked
    screw joint×1
  • 131000015576Not stocked
    non return valve×1
  • 141000015488Not stocked
    screw joint×2
  • 151000015574Not stocked
    non return valve×2
  • 161000468097Not stocked
    filter×1
  • 171000064826Not stocked
    bellow×2
  • 181000020253Not stocked
    handle×1
  • 191000072296
    $474.00
    HANDLE - 1000072296×1
  • 201000065935
    $243.56
    HANDLE - 1000065935×1
  • 211000142892Not stocked
    handle×1
  • 221000180747
    $172.11
    HANDLE - 1000180747×1
  • 231000180748
    $496.14
    HANDLE - 1000180748×1
  • 241000180749Not stocked
    handle×1
  • 251000234571
    $130.41
    retrofit kit feeler - 1000234571×1
  • 261000234573
    $444.69
    retrofit kit feeler - 1000234573×1
