DT08

DT08 step plate Diagram

Exploded parts diagram of the step plate of a Wacker Neuson DT08, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000270725
    $196.00
    Stepplate 1000270725×1
  • 21000280055
    $46.92
    BRACKET - 1000280055×1
  • 31000280056
    $46.92
    BRACKET - 1000280056×1
  • 41000272176
    $9.56
    tension spring - 1000272176×1
  • 51000280054Not stocked
    engine hood×1
  • 61000283912Not stocked
    engine hood×1
  • 71000269291
    $1.55
    HEXAGON NUT - 1000269291×2
  • 81000275865
    $18.65
    distance piece - 1000275865×2
  • 91000270677
    $4.95
    DISC SPRING - 1000270677×3
  • 101000270676
    $28.68
    distance piece - 1000270676×2
  • 111000092303
    $0.86
    Washer 10,5 St A2C - 1000092303×2
  • 121000085357
    $1.08
    hex screw - 1000085357×2
  • 131000015431Not stocked
    washer×4
  • 141000013008Not stocked
    hex screw×4
  • 151000015405Not stocked
    hexagon nut×2
  • 161000270125
    $17.34
    RUBBER BUFFER - 1000270125×4
  • 171000277902
    $6.53
    distance piece - 1000277902×6
  • 181000189891
    $65.27
    badge - 1000189891×1
  • 191000271022
    $1.90
    tension disc - 1000271022×4
  • 201000270728
    $255.19
    LOCK HOOK - 1000270728×1
  • 211000283855
    $164.67
    insulating mat - 1000283855×1
