DT08

DT08 SKIP Diagram

Exploded parts diagram of the SKIP of a Wacker Neuson DT08, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000279173
    $10,208.48
    Bucketstandard35014001Swn 1000279173×1
  • 21000283914
    $9,979.72
    Bucketstandard35014001Swn 1000283914×1
  • 31000276612
    $137.78
    Bulkplate 1000276612×1
  • 41000276618
    $88.73
    Bulkplate 1000276618×1
  • 51000276616
    $88.73
    Bulkplate 1000276616×1
  • 61000270024
    $38.34
    BUSHING - 1000270024×2
  • 71000271909
    $4.95
    WASHER - 1000271909×2
  • 81000287104
    $26.75
    shock absorber - 1000287104×2
  • 91000272651
    $82.42
    Pin 1000272651×1
  • 101000272630
    $74.55
    pivot pin - 1000272630×1
  • 111000278257Not stocked
    plate×2
  • 121000322582Not stocked
    guide rail×2
  • 131000015343Not stocked
    hex screw×4
  • 141000085390
    $0.83
    6-Point screw M8x30-8.8 A2C-DIN933 - 1000085390×6
  • 151000269276
    $1.24
    HEXAGON NUT - 1000269276×9
  • 161000085382
    $0.70
    HEX SCREW - 1000085382×9
  • 171000015430Not stocked
    u-washer×18
  • 181000015476Not stocked
    grease nipple×1
  • 191000272658
    $3.53
    PLUG - 1000272658×8
  • 201000279724
    $815.67
    Console 1000279724×1
  • 211000353280
    $2,187.80
    Console - 1000353280×1
  • 221000270731
    $38.91
    PIN - 1000270731×1
  • 231000275778
    $41.23
    PIN - 1000275778×1
  • 241000353278
    $31.99
    PIN - 1000353278×1
  • 251000085310
    $0.78
    hex screw - 1000085310×2
  • 261000269276
    $1.24
    HEXAGON NUT - 1000269276×2
  • 271000270734
    $4.07
    Washer - 1000270734×8
  • 281000272072
    $1.55
    COTTERPIN - 1000272072×1
  • 291000085391
    $0.91
    hex screw - 1000085391×2
