Track dumper

DT08PRO lub oil system Diagram

Exploded parts diagram of the lub oil system of a Wacker Neuson DT08PRO, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000003693Not stocked
    oil dip stick×1
  • 21000069738Not stocked
    o-ring×1
  • 31000324675Not stocked
    engine gasket×1
  • 41000324674Not stocked
    oil pump×1
  • 51000324919Not stocked
    hex screw×3
  • 61000004613Not stocked
    oil pressure switch×1
  • 71000324676
    $26.55
    Gear - 1000324676×1
  • 81000324678Not stocked
    hexagon nut×1
  • 91000324837Not stocked
    suction pipe×1
  • 101000003052
    $15.94
    engine oilfilter - 1000003052×1
