DW90-3
DW90-3 BRAKES Diagram
- SHIM - 1000150527×1
- pressure spring - 1000150530×4
- Piston 1000150533×2
- O-ring - 1000150534×2
- seal - 1000407642×4
- Cover 1000150536×2
- seal - 1000407643×2
- piston - 1000150539×2
- Pressureplate 1000150540×2
- TENSION SPRING - 1000106332×6
- Screw - 1000150551×6
- Friction plate - 1000150552×6
- pressure plate - 1000150553×6
- SHIM - 1000150554×2
- Screw - 1000150555×4
- SCREW - 1000150556×6
- spring - 1000150557×6
- nut - 1000150558×4
- WASHER - 1000150559×4
- drain screw - 1000150560×4
- Plug - 1000088751×4
- 221000330297Not stockedSET OF SPACERS×1
- screw - 1000106348×4
