GH3500E-GENERATOR

GH3500E Fuel Tank cpl. Diagram

Exploded parts diagram of the Fuel Tank cpl. of a Wacker Neuson GH3500E, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000074446Not stocked
    Fuel tank×1
  • 25000074092Not stocked
    Fuel tank cap×1
  • 35000053577
    $0.69
    BUSHING-TANK VALVE MOUNTING - 5000053577×1
  • 45000053576
    $21.70
    VALVE-SHUTOFF - 5000053576×1
  • 55000074091
    $6.11
    HOSE 3/16 X 14 ,FUEL HOSE - 5000074091×1
