ST45 Compact Track Loader

ST45(S04-04) instrument panel Diagram

Exploded parts diagram of the instrument panel of a Wacker Neuson ST45(S04-04), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000325121Not stocked
    Indicator instrument×1
  • 21000184001
    $125.82
    Ignition lock-R-1000125516 - 1000184001×1
  • 31000184819
    $14.17
    EZ17 Key without cap - 1000184819×1
  • 41000069027Not stocked
    cigaret lighter×1
  • 71000027006Not stocked
    Blind cover×8
  • 81000362161Not stocked
    SWITCH BEACON×1
  • 91000362156Not stocked
    SWITCH FAN×1
  • 101000052356Not stocked
    symbol×1
  • 131000362162Not stocked
    SWITCH HAZARD×1
  • 141000362106Not stocked
    switch×1
  • 151000316232Not stocked
    Control unit prop valve + switch funct×1
  • 161000362107Not stocked
    Switch×1
  • 181000362106Not stocked
    switch×1
  • 191000362242
    $83.12
    SWITCH POWER COUPLER - 1000362242×1
  • 201000312230
    $675.44
    COVER - 1000312230×1
  • 211000362158Not stocked
    SWITCH AIR CONDITIONING×1
  • 221000362159Not stocked
    SWITCH WIPER×1
  • 241000362157
    $116.58
    SWITCH WORK LIGHTS - 1000362157×1
  • 251000142881
    $31.81
    tilt switch - 1000142881×1
  • 261000362160Not stocked
    SWITCH ROAD LIGHTS×1
  • 271000361268Not stocked
    sticker 'security'×1
  • 271000353560Not stocked
    SWITCH PARK BRAKE×1
  • 291000085588
    $0.32
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×3
  • 301000081664
    $43.40
    gloves - 1000081664×1
  • 311000292881
    $1,762.44
    CONTROL UNIT - 1000292881×1
  • 321000312180Not stocked
    Flat head screw×4
  • 331000326519Not stocked
    flat head screw×4
  • 341000326575Not stocked
    sleeve×4
  • 351000292470
    $6.46
    metal-rubber buffer - 1000292470×4
