TH412 Telehandler
TH412 door Diagram
- Doorwindow 1000243868×1
- 31000365097Not stockedsealing profile×5
- bearing bush - 1000297225×4
- 51000068973Not stockedrubber buffer×1
- 61000004289Not stockedrubber disc×7
- 71000012879Not stockedquad ring×1
- HANDLE-BOWL - 1000213434×2
- EZ17 Key without cap - 1000184819×2
- Gasket - 1000213432×2
- Synthetic trim - 1000304978×2
- Cover - 1000216065×1
- screw M6x12 ISO7380-2 - 1000165459×4
- Handle - 1000448503×1
- 151000052670Not stockedovalhead screw×2
- 161000003344Not stockedlock (w/o keys)×1
- countersunk screw - 1000082349×2
- DIN985-M8-8-A2C - 1000015416×4
- Doorwindow 1000243874×1
- DOOR HINGE - 1000243875×2
- PVC Plug D=10mm - 1000297826×1
- washer - 1000066253×4
- 231000004290Not stockedrubber disc×4
- washer - 1000075544×4
- Handle - 1000208407×1
- allen screw M6x12-8.8 A2C-DIN912 - 1000085454×2
- door fastener - 1000216255×1
- Washer - 1000228571×1
- Ring - 1000216335×1
- 301000365097Not stockedsealing profile×3.3
- 311000001353Not stockedglue kt×1
- headnut - 1000298351×2
- 331000004276Not stockedcover cap×3
- 6-Point screw M8x60-8.8 A2C-DIN931 - 1000085318×1
- STRIP - 1000243876×1
- Cabdoor 1000243877×1
