WL20

WL20 engine pre heating Diagram

Exploded parts diagram of the engine pre heating of a Wacker Neuson WL20, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000264680
    $370.32
    engine preheater - 1000264680×1
  • 21000294885
    $439.42
    Engine heater Calix RE 197 - 1000294885×1
  • 31000293344
    $190.55
    connection cable - 1000293344×1
  • 41000293349
    $98.12
    Wiring harness kpl. - 1000293349×1
  • 51000294883
    $3.01
    mounting - 1000294883×1
  • 61000288851
    $3.16
    CABLE CLIP - 1000288851×1
  • 71000085494
    $1.08
    allen screw M 5x12-8.8 A2C DIN912 - 1000085494×1
  • 81000082621
    $0.74
    spring washer - 1000082621×1
  • 91000094962
    $0.04
    washer A 5,3 A2C DIN125 - 1000094962×5
  • 101000193828
    $0.89
    cable strap - 1000193828×5
  • 111000296234
    $7.81
    holder clamp - 1000296234Unknown×1
  • 111000425947Not stocked
    holder clamp×1
  • 121000085452
    $0.70
    allen screw M5x20-8.8 A2C DIN912 - 1000085452×2
  • 131000085587
    $0.03
    HEXAGON NUT - 1000085587×2
  • 141000265223
    $32.73
    Sticker - 1000265223×1
