Excavator EZ28

EZ28 driving signal (Option) Diagram

Exploded parts diagram of the driving signal (Option) of a Wacker Neuson EZ28, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000261904
    $2,048.40
    Pilotvalve 1000261904×1
  • 21000180237
    $58.54
    PRESSURE SWITCH - 1000180237×1
  • 31000124948
    $12.46
    screw seal - 1000124948×1
  • 41000190571
    $145.28
    wiring harness - 1000190571×1
  • 51000081738
    $3.95
    protecting cap - 1000081738×1
  • 61000079025
    $99.90
    reverse warner - 1000079025×1
  • 71000018400Not stocked
    hex screw×2
  • 81000095343
    $1.42
    washer A 6,4 St A2C DIN9021 - 1000095343×4
  • 91000085588
    $0.32
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×2
  • 101000000483Not stocked
    plug×2
  • 111000000456Not stocked
    pin housing×1
  • 121000095336Not stocked
    plug sleeve housing×1
  • 131000095371Not stocked
    plug sleeve×1
  • 141000139516
    $1.60
    cable lug - 1000139516×1
  • 151000097890
    $4.47
    cable - 1000097890×0.5
  • X11000095336Not stocked
    plug sleeve housing×1
  • X21000000481Not stocked
    plug housing×1
  • X31000027435Not stocked
    insulating sleeve×2
  • X41000095371Not stocked
    plug sleeve×1
