Excavator EZ28

EZ28 cooling system Diagram

Exploded parts diagram of the cooling system of a Wacker Neuson EZ28, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000148813
    $667.00
    Waterpump 1000148813×1
  • 21000148818
    $18.22
    SEAL WATER PUMP - 1000148818×1
  • 31000293674
    $12.84
    O-ring - 1000293674×1
  • 41000148814
    $42.66
    ENGINE GASKET - 1000148814×1
  • 51000073611
    $84.47
    THERMOSTAT HOUSING - 1000073611×1
  • 61000148389
    $82.36
    THERMOSTAT - 1000148389×1
  • 71000063425Not stocked
    lock screw×1
  • 81000002929Not stocked
    seal ring×1
  • 91000280078
    $31.64
    Temperature - 1000280078×1
  • 101000149740
    $70.52
    Belt pulley - 1000149740×1
  • 111000085211
    $81.54
    FAN SPACER - 1000085211×1
  • 121000269598
    $2.24
    copper ring - 1000269598×1
