Vibroplate WP KMAT
WPKMAT Motor housing - Piston Diagram
- Motor housing cpl. - 5100067155×1
- Rotary shaft seal - 5100067176×1
- Gasket - 5100067225×1
- Drain screw - 5100067164×1
- Crankshaft - 5100067249×1
- Grooved ball bearing - 5100067167×1
- Grooved ball bearing - 5100067167×1
- Motor housing cover - 5100067233×1
- Rotary shaft seal - 5100067176×1
- Hexagonal head cap screw - 5100067244×6
- Woodruff key - 5100067158×1
- Piston cpl. - 5100067159×1
- Piston cpl. 0,01 - 5100067160×1
- Piston cpl. 0,02 - 5100067161×1
- Piston ring - 5100067162×1
- Piston ring 0,01 - 5100067163×1
- Piston ring 0,02 - 5100067165×1
- Retaining ring - 5100067166×1
- Piston pin - 5100067168×1
- Connecting rod - 5100067169×1
- Covering - 5100067173×1
- Camshaft - 5100067177×1
- Hexagonal head cap screw - 5100067182×1
- Washer - 5100067195×1
- Sleeve - 5100067196×1
- Governor lever cpl. - 5100067198×1
- Covering - 5100067207×1
- Hexagonal head cap screw - 5100067181×2
- Fitting key - 5100067215×1
- Washer - 5100067217×1
- Nut - 5100067224×1
- Dip stick - 5100067226×1
- Screw - 5100067228×1
- Cotter pin - 5100067231×1
- Governor shaft - 5100067232×1
- Fixing pin - 5100067236×2
- Fixing pin - 5100067189×2
- Fixing pin - 5100067189×2
- Label - 5100067252×1
