ET145

ET145 Engine bedding Diagram

Exploded parts diagram of the Engine bedding of a Wacker Neuson ET145, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000015381Not stocked
    hex screw×18
  • 21000015450Not stocked
    northlock disc×14
  • 31000350997Not stocked
    engine lodging×1
  • 41000368133
    $19.36
    pipe - 1000368133×2
  • 51000094970
    $1.71
    Nord-Lock disc NL12x25,4 - 1000094970×4
  • 61000020127Not stocked
    hexagon nut×2
  • 71000324899Not stocked
    mounting bracket×1
  • 81000295243
    $109.38
    Mountingbracket 1000295243×1
  • 91000293498
    $88.34
    Mountingbracket 1000293498×1
  • 101000067554Not stocked
    hydro.bearing×2
  • 111000012361Not stocked
    hydro.bearing×2
  • 121000085515
    $1.10
    cheese head screw - 1000085515×2
  • 131000082609
    $0.73
    lock washer - 1000082609×2
  • 141000304110
    $11.51
    WASHER - 1000304110×4
  • 151000085411
    $1.37
    hex screw M10x20-8.8 A2C DIN933 - 1000085411×8
  • 161000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×8
  • 171000015438Not stocked
    lock washer×8
  • 181000032218Not stocked
    pipe clamp×1
  • 191000018400Not stocked
    hex screw×1
  • 201000015436Not stocked
    lock washer×1
  • 211000015430Not stocked
    u-washer×1
