ET145

ET145 lub oil system Diagram

Exploded parts diagram of the lub oil system of a Wacker Neuson ET145, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000311470Not stocked
    oildip stick×1
  • 21000311522Not stocked
    oildip stick×1
  • 31000310830
    $37.99
    Seal - 1000310830×1
  • 41000311033Not stocked
    oil pump×1
  • 51000311034
    $12.71
    screw - 1000311034×3
  • 61000310728Not stocked
    oil pressure switch×1
  • 71000310829
    $510.39
    aggregate - 1000310829×1
  • 81000310808
    $811.97
    oildip stick - 1000310808×1
  • 91000310810
    $1.72
    O-ring - 1000310810×2
  • 101000310861Not stocked
    seal plate×2
  • 111000312607Not stocked
    seal ring×2
  • 121000309594
    $85.43
    Filter - 1000309594×1
  • 131000310827Not stocked
    seal ring×2
  • 141000310862Not stocked
    seal plate×1
  • 151000310803Not stocked
    suction pipe×1
  • 161000310804
    $13.50
    O-ring - 1000310804×1
  • 171000312608
    $8.99
    screw - 1000312608×1
