ET145
ET145 track tensioner complete Diagram
- Tracktensionercomplete 1000176917×2
- non return valve - 1000232922×2
- screw seal - 1000124948×2
- allen screw M12x50 10.9 - 1000085512×4
- 51000426231Not stockedlock washer×4
- Springassembly 1000286588×2
- Roller 1000286587×2
- SCRAPER - 1000083471×2
- Tensioncylinder 1000279279×2
- seal kit tension wheel - 1000286584×2
- BUSHING - 1000286519×4
- Forkloding 1000286581×4
- Shaft 1000286520×2
- PLUG - 1000286582×4
- SCREW - 1000286586×4
- SPRING WASHER - 1000061352×4
- GROOVED RING - 1000083532×2
