DW60 Dumper

DW60 speed actuating Diagram

Exploded parts diagram of the speed actuating of a Wacker Neuson DW60, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000359600Not stocked
    accelerator pedal×1
  • 21000312048Not stocked
    step plate×1
  • 31000323935Not stocked
    bowden cable×1
  • 41000015407Not stocked
    hexagon nut×1
  • 51000085391
    $0.91
    hex screw - 1000085391×1
  • 61000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×1
  • 71000085588
    $0.32
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×3
  • 81000015430Not stocked
    u-washer×6
  • 91000301024
    $8.64
    angle bracket - 1000301024×1
  • 101000085457
    $0.13
    allen screw M6x25-8.8 A2C DIN912 - 1000085457×3
  • 111000333513
    $52.81
    extension - 1000333513×1
  • 121000013027Not stocked
    washer×2
  • 131000085412
    $0.87
    6-Point screw M10x40-8.8 A2C-DIN933 - 1000085412×1
  • 141000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×1
  • 151000181308
    $8.32
    BUSHING - 1000181308×1
  • 161000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×2
