DW60 Dumper

DW60 combicooler Diagram

Exploded parts diagram of the combicooler of a Wacker Neuson DW60, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000323451
    $3,065.60
    combicooler - 1000323451×1
  • 21000344675
    $4,468.51
    COOLER - 1000344675×1
  • 31000390832
    $4,328.78
    combi Cooler D18 - 1000390832×1
  • 41000015345
    $1.55
    Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×5
  • 51000324900
    $108.25
    rail - 1000324900×1
  • 61000247396
    $17.97
    cooler cap - 1000247396×1
  • 71000309165Not stocked
    seal strap foam×1.9
  • 81000130316
    $150.54
    non return valve - 1000130316×1
  • 91000325469Not stocked
    view glass×1
  • 101000264009
    $12.00
    screw joint 8mm / 1/2" -20 UNF-28 - 1000264009×3
  • 111000015499Not stocked
    screw joint×1
  • 121000326728Not stocked
    ring×1
  • 131000331394Not stocked
    ring×1
  • 141000083069Not stocked
    screw joint×1
  • 151000015364Not stocked
    hex screw×2
  • 161000085390
    $0.83
    6-Point screw M8x30-8.8 A2C-DIN933 - 1000085390×14
  • 171000187994
    $36.72
    thread plate - 1000187994×1
  • 181000020127Not stocked
    hexagon nut×1
  • 191000085613
    $0.10
    washer - 1000085613×2
  • 201000085332
    $1.31
    HEX SCREW - 1000085332×1
  • 211000082615
    $1.66
    WASHER - 1000082615×1
  • 221000105025
    $63.79
    METAL- RUBBER BUFFER - 1000105025×1
  • 231000324640Not stocked
    bracket cooler×1
  • 241000017845Not stocked
    rubber profile×3.5
  • 251000015437Not stocked
    lock washer×16
  • 261000323450Not stocked
    water hose×1
  • 271000323449Not stocked
    water hose×1
  • 281000336087Not stocked
    hose clamp×2
  • 291000325015Not stocked
    hose clamp×2
  • 301000303516
    $22.99
    hose clamp - 1000303516×1
  • 311000165515
    $25.75
    hose clamp - 1000165515×5
  • 321000324663
    $44.22
    Bracket 1000324663×1
  • 331000328441Not stocked
    air pipe×1
  • 341000085411
    $1.37
    hex screw M10x20-8.8 A2C DIN933 - 1000085411×3
  • 351000068303
    $5.93
    clamp - 1000068303×2
  • 361000328953Not stocked
    air suction hose×1
  • 371000323455Not stocked
    air suction hose×1
  • 381000323454Not stocked
    air suction hose×1
  • 391000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×8
  • 401000092303
    $0.86
    Washer 10,5 St A2C - 1000092303×10
  • 411000329489
    $804.22
    scoop - 1000329489×1
  • 421000329490
    $850.91
    scoop - 1000329490×1
  • 431000309165Not stocked
    seal strap foam×1.8
  • 441000013027Not stocked
    washer×14
  • 451000013027Not stocked
    washer×2
  • 461000015438Not stocked
    lock washer×3
  • 471000013008Not stocked
    hex screw×2
  • 481000019136Not stocked
    hex screw×2
  • 491000323452Not stocked
    air cooler×1
  • 501000339038
    $851.59
    Intercooler - 1000339038×1
  • 511000344677Not stocked
    air cooler×1
  • 521000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×10
  • 531000390879Not stocked
    screwend piece×1
  • 541000390986Not stocked
    seal ring×1
