DW60 Dumper

DW60 AXLE Diagram

Exploded parts diagram of the AXLE of a Wacker Neuson DW60, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000322371Not stocked
    front axle×1
  • 21000110250
    $20.15
    HEX SCREW - 1000110250×4
  • 31000106398
    $2.91
    NORTHLOCK DISC - 1000106398×8
  • 41000085579
    $4.24
    HEXAGON NUT - 1000085579×4
  • 51000322360Not stocked
    rear axle×1
  • 61000047559Not stocked
    hex screw×8
  • 71000321993Not stocked
    plate×4
  • 81000275081
    $126.59
    axle bracket - 1000275081×4
  • 91000094973
    $2.49
    NORTHLOCK DISC - 1000094973×16
  • 101000021948Not stocked
    hexagon nut×8
  • 111000085502
    $0.88
    allen screw M10x30 Geomet 500A DIN912 - 1000085502×16
  • 121000429636Not stocked
    cardan shaft×1
  • 131000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×16
  • 141000000573Not stocked
    screw joint×1
  • 151000083062
    $14.89
    GEO12LM14X1,5OMDA3C - 1000083062×2
  • 161000108438
    $15.82
    GE08LM14X1,5OROMDA3C - 1000108438×2
  • 171000015518
    $8.71
    ET08LOMDA3C - 1000015518×1
  • 181000000542
    $11.08
    EW08LOMD - 1000000542×1
  • 191000324786Not stocked
    axle bracket×2
  • 201000015519
    $12.63
    ET12LOMDA3C - 1000015519×1
