G35
G35 Intake/Exhaust Diagram
- 15100030055Not stockedIntake manifold gasket×1
- 25100030056Not stockedManifold×1
- 35100030057Not stockedIntake manifold gasket×2
- 45200016485Not stockedFlange×1
- 55200016486Not stockedScrew×4
- GASKET-INTAKE FLANGE - 5100060383×2
- 75100030058Not stockedIntake manifold gasket×1
- 85100030059Not stockedIntake manifold×1
- SCREW M8 X 35 - 5000084171×6
- 105200016495Not stockedFlange×1
- 115200016496Not stockedScrew×8
- TURBOCHARGER - 5100030060×1
- BENJO BOLT M10x1x22 - 5100044911×2
- Copper washer D14/10.2 1 - 5000082183×4
- 175100030061Not stockedOil pipe×1
- Nut - 5000206130×3
- Oil pipe - 5100061837×1
- 205200016503Not stockedOil pipe×1
- 215200016433Not stockedClamp×2
- BOLT M6 X 1 X 12 - 5000159253×2
- GASKET - 1000430253×1
- 245100029468Not stockedStud×1
- 255200016507Not stockedClamp×3
- 265100030063Not stockedBlow-by pipe×1
- Exhaust manifold - 5100061842×1
- 285200016510Not stockedGasket×1
- 295200016511Not stockedGasket×3
- Stud 8X1, 25X20 - 5100016074×3
- 315200016512Not stockedFlange nut×8
- 325100029469Not stockedStud×4
- FLANGE - 5100030067×1
- NUT-COPPER - 5000086331×7
- 355100029471Not stockedStud×8
- 365200016515Not stockedTurbo gasket×1
- 375200016532Not stockedHeater×1
- Washer - 5000082293×4
- 395200016496Not stockedScrew×4
- 405200016534Not stockedCable×1
