G35

G35 Lug Box Diagram

Exploded parts diagram of the Lug Box of a Wacker Neuson G35, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100058035
    $549.88
    PANEL-LUG BOX,MG - 5100058035×1
  • 25100058032
    $151.04
    PANEL-LUG DOOR,MG - 5100058032×1
  • 35100058023
    $62.84
    GUARD-LUG BOX,RUBBER,MG - 5100058023×1
  • 45100058024
    $168.34
    PLATE-RETAINER,MG - 5100058024×1
  • 55000158696
    $13.92
    HINGE-LUG DOOR - 5000158696×1
  • 65000158784
    $37.31
    LATCH-NONLOCK,FLUSH,P.BTN - 5000158784×1
  • 75000029116
    $0.18
    SCREW M6 X 1 X 20,FLANGE LOCK - 5000029116×6
  • 85200020974Not stocked
    Hexagonal flange head screw×6
  • 95100058926
    $0.46
    SCREW-M8x16,THD.FRM,HEX.FLG.MGCT 565 - 5100058926×1
  • 105100058923
    $2.32
    BOLT-CARRIAGE.SHRT.NK-M8x20-8.8-MAG565 - 5100058923×2
  • 115000029117
    $0.03
    NUT-LOCK M6,HEX,SERR,FLANGE - 5000029117×12
  • 125000030066
    $0.16
    NUT-LOCK M8,HEX,SERR.,FLANGE - 5000030066×2
  • 135100068044
    $5.20
    Switch actuator - 5100068044×2
  • 145100068045
    $29.26
    Magnet switch - 5100068045×2
