G35

G35 Terminal Lugs Diagram

Exploded parts diagram of the Terminal Lugs of a Wacker Neuson G35, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15200000991
    $23.35
    LUG-TERMINAL, 350 MCM - 5200000991×5
  • 25100061276
    $252.31
    PLATE-LUG,GLASTIC,MG - 5100061276×1
  • 35000111218
    $1.68
    SCREW M6 X 30,HX.HD,SER - 5000111218×4
  • 45000011452
    $0.44
    SCREW M8 X 50 HX.HD. - 5000011452×3
  • 55100044816
    $22.77
    STUD-M8x100-8.8-ZNC - 5100044816×2
  • 65000010622
    $0.10
    WASHER-FLAT,M8,ZINC - 5000010622×3
  • 75000010882
    $0.05
    NUT M8 8,HEX - 5000010882×7
  • 85000030066
    $0.16
    NUT-LOCK M8,HEX,SERR.,FLANGE - 5000030066×5
  • 95000115570
    $0.12
    Nut M8 Flange, Non serrated - 5000115570×2
  • 101000343345
    $0.14
    NUT M6 FLANGED LOCK 10 ZINC - 1000343345×4
  • 115100061589
    $5.42
    CONNECTOR-BUS BAR,L0-GND,MG - 5100061589×1
