TH412

TH412(T01-01) floor plate Diagram

Exploded parts diagram of the floor plate of a Wacker Neuson TH412(T01-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000015343Not stocked
    hex screw×4
  • 201000015431Not stocked
    washer×4
  • 301000498592
    $408.68
    Floor plate cpl. V2 - 1000498592×1
  • 401000013027Not stocked
    washer×4
