WL28

WL28(A01-01) rear axle Diagram

Exploded parts diagram of the rear axle of a Wacker Neuson WL28(A01-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000465773Not stocked
    axle pipe×1
  • 21000465774Not stocked
    axle pipe×1
  • 31000465777Not stocked
    axle shaft×1
  • 41000245528
    $1,996.98
    Axleshaft 1000245528×1
  • 51000210215
    $845.30
    Cover 1000210215×2
  • 61000210247
    $191.07
    Ring - 1000210247×2
  • 71000225253
    $45.53
    Bearing - 1000225253×2
  • 81000222514
    $45.30
    Nut - 1000222514×2
  • 91000225696
    $17.97
    SEAL-OIL - 1000225696×2
  • 101000224919
    $1.99
    O-RING - 1000224919×2
  • 111000465787Not stocked
    differential housing×1
  • 121000466384Not stocked
    pinion set×1
  • 131000225309
    $85.53
    Bearing - 1000225309×1
  • 141000225681
    $73.43
    Bearing - 1000225681×1
  • 151000466713Not stocked
    taper roller bearing×1
  • 161000466717Not stocked
    taper roller bearing×1
  • 171000470536Not stocked
    o-ring×1
  • 181000466722Not stocked
    o-ring×2
  • 191000085355
    $1.51
    hex screw - 1000085355×8
  • 201000378696Not stocked
    hex screw×14
  • 211000465653Not stocked
    hex screw×16
  • 221000465765Not stocked
    set nut×1
  • 231000049435Not stocked
    lock plate×1
  • 241000085307
    $11.32
    lock screw - 1000085307×1
  • 251000013057Not stocked
    seal ring×1
  • 261000223412
    $2.61
    FITTING DISC - 1000223412×1
  • 271000223414
    $2.61
    FITTING DISC - 1000223414×1
  • 281000223167
    $1.84
    RING-SHIM - 1000223167×1
  • 291000223168
    $11.95
    RING-SHIM - 1000223168×1
  • 301000223169
    $3.39
    RING-SHIM - 1000223169×1
  • 311000223170
    $3.87
    RING-SHIM - 1000223170×1
  • 321000457604
    $44.45
    RING-SHIM - 1000457604×1
  • 331000457607
    $48.95
    RING-SHIM - 1000457607×1
  • 341000457609
    $44.45
    RING-SHIM - 1000457609×1
